Wurlitzer 200A Amplifier Rebuild Kit
Wurlitzer 200A Amplifier Rebuild Kit
This kit includes the parts to rebuild and repair most issues with your model 200A Wurlitzer amplifier.
Share this Product
Product Details
Description
Whats Included
Instructions
Description
This kit includes the parts to rebuild and repair most issues with your model 200A Wurlitzer amplifier. See Instructional Tab for Schematic and Transistor Pinouts.
Notes:
• To ensure you receive the correct
components for your piano, please be certain that your piano is a 200A model before placing your
order. There is a 15% restocking fee for this product.
• Replacement Transistor
Pinouts May Not Match Original. See Instructions Tab for Schematic and Transistor
Pinouts
•We do not offer instructions or technical support for this
item other than what is listed here.
• Improper installation or use
will void any and all warranty.
• Installation of this product is performed at your own risk.
Working on electronic equipment poses an inherent risk to oneself, others and personal
property. Vintage Vibe assumes no liability for the consequences of the attempted installation
of this product. If you are not confident in your abilities to perform this type
of installation you may send the unit to us for service.
Whats Included
STANDARD CAP KIT:
• All Electrolytic Capacitors
COMPLETE KIT:
• Everything in the STANDARD CAP KIT
• 200A Hiss Killer Kit
DELUXE KIT:
• Everything in the STANDARD CAP KIT
• Everything in the COMPLETE KIT
• Board Fuse Mod (X2)
• Complete 200A Transistor Set*
*The kit will contain two sets of TR15 and TR16 transistors marked “EARLY and “LATE”. Late model aux-out production started at serial #102905 (schematic #203720-S-3). If your piano’s serial number falls before this, use the EARLY set of transistors. If your piano’s serial number is later, then use the LATE set.
